Self-loading stacking trailer - SIPMA WS 6510 DROMADER
SIPMA WS 6510 DROMADER trailer is a multi-purpose selfloading low-chassis trailer with a loading capacity of 6.5 tons. The trailer slips its side fork under a bale and picks it up it from the ground. The bale is then moved by special arms towards the rear part of the body in order to make space for next bales.
SIPMA WS 6510 DROMADER trailer is a multi-purpose selfloading low-chassis trailer with a loading capacity of 6.5 tons. The trailer slips its side fork under a bale and picks it up it from the ground. The bale is then moved by special arms towards the rear part of the body in order to make space for next bales.
- Load body design enables the trailer to collect and transport bales (up to 8 bales with the diameter of 1.2 - 1.5 m), crops and other materials (e.g. sand).
- Hydraulic distributor enables control from the cabin and ensures large comfort of work and high efficiency.
- Support foot increases the stability of the trailer during the loading of heavy green fodder bales and also improves the safety of work.
- Pneumatic brakes on all wheels and hand brake guarantee high safety of work.
- Road lights allow the machine to be used on public roads without incurring additional costs.
- Tandem chassis (rigid axles) and reinforced structure increase durability and resistance providing a load capacity of 6.5 t.
- Hydraulic acutator ensures bale unloading to the side, sliding backwards and vertical stacking, enabling adaptation to the different needs of users.
| Model | WS 6510 DROMADER | |
|---|---|---|
| Capacity | t | 6.5 |
| Maximum bales number | pcs. | 8 |
| Maximum bales weight | kg | 800 |
| Backward dumping angle | 90° | |
| Side dumping angle | 45° | |
| Maximum speed | km/h | 25 |
| Power demand | kW (HP) | 60 (82) |
| Load box dimensions | ||
| length | mm | 4000 |
| width | mm | 2200 |
| height | mm | 370 |
| Dimensions of the stacking trailer | ||
| length | mm | 6440 |
| width | mm | 2630 |
| height | mm | 3200 |
| Weight | kg | 2610 |
